Technical Data
Tyre Specifications
Comprehensive technical dimensions, tread depth, base thickness, and dual-length weight metrics engineered for maximum fleet safety and durability.
19Precision Sizes
11 - 16.6 mmTread Depths
HW & LWSpecialist Formats
ISO 9001Quality Tested
Tyre Technical Matrix
Showing 19 of 19 records| Tyre Size | Base Width (mm) | Tread Depth (mm) | Base Thickness (mm) | Total Thickness (mm) | Low Length Tread | High Length Tread | ||
|---|---|---|---|---|---|---|---|---|
| Length (in) | Weight (Kg) | Length (in) | Weight (Kg) | |||||
| LCV | 148 | 11.0 | 3.5 | 14.5 | 93 | 5.0 kg | - | - |
| 1000 X 20 | 205 | 14.0 | 3.5 | 17.5 | 128 | 11.3 kg | 148 | 13.0 kg |
| 1000 X 20HW | 205 HW | 16.0 | 4.0 | 20.0 | 128 | 12.5 kg | - | - |
| 1000 X 20LW | 205 LW | 13.0 | 3.3 | 16.3 | 127 | 10.0 kg | - | - |
| 1000 X 20 | 210 | 14.0 | 3.5 | 17.5 | 128 | 11.4 kg | 148 | 13.2 kg |
| 1000 X 20HW | 210 HW | 16.0 | 4.0 | 20.0 | 128 | 12.7 kg | - | - |
| 1000 X 20 | 215 | 14.6 | 4.0 | 18.6 | 128 | 11.7 kg | 148 | 13.5 kg |
| 1100 X 20 | 215 | 14.6 | 4.0 | 18.6 | 133 | 12.2 kg | - | - |
| 1100 X 20HW | 215 HW | 16.6 | 4.0 | 20.6 | 133 | 13.5 kg | - | - |
| 1000 X 20 | 220 | 14.6 | 4.0 | 18.6 | 128 | 11.8 kg | 148 | 13.7 kg |
| 1000 X 20HW | 220 HW | 16.6 | 4.0 | 20.6 | 128 | 13.3 kg | - | - |
| 1000 X 20 | 225 | 14.6 | 4.0 | 18.6 | 128 | 12.3 kg | 148 | 14.2 kg |
| 1100 X 20 | 225 | 14.6 | 4.0 | 18.6 | 133 | 12.8 kg | - | - |
| 1000 X 20 | 230 | 14.6 | 4.0 | 18.6 | 128 | 12.5 kg | 148 | 14.4 kg |
| 1000 X 20HW | 230 HW | 15.0 | 5.0 | 20.0 | 128 | 13.7 kg | 148 | 15.8 kg |
| 1100 X 20 | 235 | 14.6 | 4.0 | 18.6 | 133 | 13.2 kg | 148 | 14.7 kg |
| 1000 X 20 | 240 | 14.6 | 4.0 | 18.6 | 128 | 12.9 kg | - | - |
| 1200 X 20 | 240 | 14.6 | 4.0 | 18.6 | - | - | 148 | 14.9 kg |
| 1200 X 20HW | 240 HW | 16.6 | 4.0 | 20.6 | 128 | 14.5 kg | 148 | 16.8 kg |
Abbreviations & Designations
- LCV: Light Commercial Vehicle pattern designed for urban and regional multi-stop delivery routes.
- HW (Heavy Weight): Reinforced tread compound with increased tread depth and base thickness for high-stress terrain and heavy payloads.
- LW (Light Weight): High-efficiency reduced weight tread compound optimized for long-distance highway line-haul fuel economy.
Engineering Standards
- Total Thickness: Calculated as the aggregate of precision Tread Depth plus Base Cushion Thickness.
- Dual-Length Options: Both standard low-length and extended high-length configurations available to fit varied casing diameters.
- Casing Quality: All retreading lines conform to rigorous ultrasonic and shearography casing standards.
